Detection tuning

Out of the box, Fregata runs a bundled YOLOv9-tiny model at 320×320 on the Apple Neural Engine. This is fast (~1–4 ms per frame), private (it’s an ONNX file inside the app bundle, no cloud), and “good enough” for porches, driveways, and most outdoor uses. This page covers everything you’d reach for when “good enough” isn’t.

What’s running, by default

The defaults that ship with the app:

detectors:
  coreml:
    type: coreml
    inference_backend: ane     # "ane" | "gpu"
    coreml_flags: 0
    model:
      model_type: yolo-generic
      width: 320
      height: 320
      input_tensor: nchw
      input_pixel_format: rgb
      input_dtype: float

Translated:

• type: coreml — the only detector type that ships in Fregata. No EdgeTPU, TensorRT, OpenVINO, ROCm, RKNN, Hailo. Those don’t apply on macOS. (For the full list of what’s removed, see Fregata vs Frigate.)
• inference_backend: ane — route inference through ONNX Runtime’s CoreML execution provider, in NeuralNetwork format, preferring the ANE. Fall through to the GPU or CPU only when ops aren’t supported. Switch to gpu to force MLProgram + Metal.
• coreml_flags: 0 — 0 lets the runtime pick ANE/GPU/CPU freely; 1 excludes the ANE.
• model_type: yolo-generic — generic YOLO postprocessor. Other supported types: yolox, yolonas, dfine, rfdetr, ssd.

ANE vs GPU — which should I use?

The honest answer: leave it on ane and don’t think about it again for the bundled model and the typical Frigate+ models. The ANE is the faster path on Apple Silicon for INT8 / FP16 YOLO-shaped networks, and the runtime falls back automatically when an op isn’t supported.

Switch to inference_backend: gpu when:

• You’re running a model the CoreML compiler can’t lower onto the ANE (you’ll see this on first warmup as a CPU-tier latency).
• You want to A/B test latency or thermals on a specific machine.
• You’re hitting a known ANE bug on a specific macOS build and need to ship a fix today.

On an M1 Pro, ANE inference for YOLOv9-tiny at 320×320 is in the 1–2 ms range; GPU is 4–8 ms; CPU is 40–80 ms. The CPU path is correctness-only — never run a real install on it.

Masks

Masks blank out parts of the frame before motion detection runs, which is the right place to ignore tree branches, your neighbour’s front porch, and anywhere a flag waves all day.

Two flavours:

cameras:
  front_porch:
    motion:
      mask:
        - 0,0,0,400,300,400,300,0
    objects:
      filters:
        person:
          mask:
            - 800,0,1280,0,1280,200,800,200

• motion.mask — pixels excluded from motion altogether. No motion signal, no detector pass, no event.
• objects.filters.<class>.mask — pixels where a detection of that class is suppressed even if motion got us there. Use this for “ignore the person on the TV” scenarios.

The web UI has a polygon editor under Settings → Masks & Zones. Draw, save, repeat.

Zones

Zones are named polygons. They don’t change whether an object is detected — they change what events that detection creates and what gets sent to MQTT or Home Assistant.

cameras:
  driveway:
    zones:
      driveway_apron:
        coordinates: 0,720,400,720,500,500,0,500
        objects:
          - car
          - truck
      mailbox:
        coordinates: 1100,400,1280,400,1280,500,1100,500

A car event in driveway_apron will fire as a zone-entry event. A person walking past the mailbox won’t, because mailbox doesn’t list person.

This is the same configuration shape upstream Frigate uses; their zones documentation covers more advanced shapes.

Per-object thresholds

The bundled YOLO model returns a confidence score for every box. A sensible default is to ignore anything under ~0.5, and to be stricter (~0.7) for classes that are easy to confuse with similar objects:

objects:
  track:
    - person
    - car
    - dog
  filters:
    person:
      threshold: 0.7
      min_area: 1500
    dog:
      threshold: 0.65

min_area is in pixels; it kills tiny detections — usually distant people that hover at low confidence.

Bringing your own model

Fregata supports any ONNX model that ONNX Runtime’s CoreML provider can run. The most common reasons to swap:

1. You bought a Frigate+ subscription and want to use your custom-trained model. See below.
2. You’ve trained YOLOv9 / YOLOv10 / RT-DETR yourself and have an onnx export. Drop it in.
3. You want classes the bundled model doesn’t have — e.g. bicycles, packages, license plates, drones.

Place the ONNX file somewhere persistent (the conventional spot is ~/Fregata/config/models/my_model.onnx) and point the config at it:

detectors:
  coreml:
    type: coreml
    inference_backend: ane
    model_path: /Users/<you>/Fregata/config/models/my_model.onnx
    model:
      model_type: yolo-generic   # or yolox, yolonas, dfine, rfdetr, ssd
      width: 640
      height: 640
      input_tensor: nchw
      input_pixel_format: rgb
      input_dtype: float
      labelmap_path: /Users/<you>/Fregata/config/models/labels.txt

The labelmap_path is a plain text file with one class label per line, matching the model’s output indices. If you skip it, Fregata falls back to the COCO label map that ships with the app.

Frigate+

Frigate+ models work natively. You’ll see them on your account dashboard with a plus://... identifier; paste that into model_path:

detectors:
  coreml:
    type: coreml
    model_path: plus://abc123def456

Fregata fetches the model into ~/Fregata/config/model_cache/ on first launch and validates the architecture. It checks the model’s declared supportedDetectors field for onnx (CoreML maps to ONNX under the hood); if your Frigate+ model is older than the onnx-support cutover, retrain on the dashboard for free.

Note

Frigate+ training and account management lives at frigate.video/plus. Fregata doesn’t resell or proxy it — your subscription is directly with the Frigate project. Fregata just consumes the resulting model file.

Verifying a model swap worked

After a config reload (or Restart Frigate from the tray):

1. Watch the Detector row in the tray. The first inference logs a warmup-tier classification — ANE, GPU, or CPU. CPU after a model swap usually means an unsupported op.
2. Open the web UI’s System tab. The “Detector inference time” chart should plateau within a few seconds at the same tier.
3. Send an obvious test through (walk past the camera, drop a package). If the bounding box is centred on the right object, you’re done.

If the inference time has jumped from ~2 ms to 50+ ms, you’ve fallen back to CPU. Either set inference_backend: gpu or re-export the model with op set ≤ 17 — see Troubleshooting.
